Rated frequency (Hz) |
50 60 |
Rated output(kVA) |
1.7 2.0 |
Max. ouput (kVA) |
2 2.5 |
Rated voltage (V) |
115/230 120/240 |
Rated current (A) |
14.8/7.4 16.7/8.3 |
Rated speed (r/min ) |
3000 3600 |
Phase NO. |
Single phase |
Power factor £¨cos¥õ£© |
1.0 |
Insulation grade |
B |
Pole number |
2 |
Excitation mode |
Self-Excitation and constant voltage(AVR) |
panel type |
General Panel |
Volage (V) |
115/230 120/240 |
Output Receptacle (mm) |
Two receptacles |
Connection pole |
N/A |
DC12V output |
Connection pole output |
Overall dimension:L¡¿W¡¿H(mm) |
640¡¿480¡¿530 |
Dry weight (Kg) |
X:53 E:60 |
Working assorting weight(Kg) |
X:66 E:73 |
Noise Level(7M) db(A) |
77 |
Structure type |
Open frame |
Engine Model |
KM170FG |
Engine type |
Single-cylinder,vertical,four-storke,direct injection |
Cylinder NO,-bore¡¿stroke(mm) |
1-70¡¿55 |
Displacement |
211 |
Rated power[kW(Hp)/(r/min)] |
2.5/3000 2.8/3600 |
Compression ratio |
20:1 |
Rated rotation speed |
3000 3600 |
lgnition system |
- |
Cooling system |
Air cooled |
Lubrication system |
Pressure splashed |
Starting system |
X:Recoil E:Electric Starter |
Fuel type |
0#(summer)-10#(winter)-35#(chillness) disel |
Lube oil Brand |
CDgrade or SAE10W-30,15W-40 |
Capacity of cooling Water(L) |
N/A |
Lube capacity (L) |
0.75 |
Starting motor capacity (V-kW) |
12V 0.8kW |
Charging generator capacity (V-A) |
12V 3A |
Battery capacity(V-Ah) |
12V 36Ah |
Fuel consumption (g/kW¡¤h) |
¡Â370 |
Fuel tank capacity (L) |
13.5 |
Continuous running time (hr) |
14.5 |
